Tomix N Turnout Track (Left Turn) 541mm 15°

Tomix N Turnout Track (Left Turn) 541mm 15°

$41.99

Description

This is a standard TOMIX point made of synthetic resin sleeper that is 140mm long and branches to the left at a curve radius of 541mm at 15°.

Features

  • Adopts a complete selection system and can be used as a spring point
  • Operates by a combination of point control box N and power unit N
  • Branches to double track spacing of 37 mm when combined with C541-15 rail
  • Double track spacing of 37 mm at a distance of 280 mm when using 2 rails Achieves a one-way wire
  • Gaps are realized by replacing with an insulated joiner (sold separately)
  • Point N drive unit common to fine trucks is built into the track bed
  • A system that completely switches the + - energization of the two rails. Fully selectable, allowing you to enjoy reverse operation and complex point installations with simple electrical wiring.Dummy point motor included.Durable die-cast molded tip rail.Synthetic sleeper expression, painted ballast and sleepers for a beautiful appearance . snaps together with a claw, making for an easy and reliable connection.
  • The joiner uses an improved joiner .
  • Compatible with conventional TOMIX rails.
  • Electric synthetic sleeper point N-PL541-15-SY(F)

Accessories

  • Dummy point motor runner
  • Dummy point switching machine runner

Specifications

Brand Tomix
