Tamiya 1/12 FMC XR311 Vintage Re-Release RC Kit 58004

Tamiya 1/12 FMC XR311 Vintage Re-Release RC Kit 58004

$339.00

Description

The XR311 is a re-release kit that was originally available in 1977. It was Tamiya's first suspension equipped RC buggy. The 2012 re-release incorporates modern improvements while maintaining the basic layout of the original.

Inclusions:

XR311 Combat Support Vehicle Kit with Tires
Wheels
ESC
Body
Driver Figure
Motor and Instruction Manual

Specifications:

Scale: 1/12
Terrain Use: Multi-purpose
Overall length: 405mm
Overall width: 173mm
Overall height: 135mm
Clearance: 15mm
Wheelbase: 260mm
Total weight: approx. 1800g
Drive system: Rear wheel 2 wheel drive
Tire width (front and rear): 29mm
Tire diameter (front/rear): 75mm
Tread (front/rear): 140/144mm
Tread pattern (front and rear): Balloon Tire
Frame: Channel Duralumin
Steering tie rod: 2 Split
Suspension (both front and rear): Double Wishbone / Torsion Bar Spring
Gear ratio: 9.3: 1, 16: 1, 21: 1
Adjustable Gear Ratio: Yes
Bearings: Plastic Bushing
Body Material: ABS Plastic
Chassis Material: Aluminum
Construction Type: Assembly Kit
Differential Type: Gear
Drive Type: Gearbox
Motor: 540-brushed type
Shock Damper: Friction Damper
Suspension: Fully Independent Double Wishbone
Led Light Buckets: No
Led Lights: No

Requires:

Assembly: Radio system (transmitter and receiver)
Steering servo: 7.2V NiMh
Battery and battery charger

For realistic paint scheme, use the following Tamiya paints:

TS-28 Olive Drab
XF-10 Flat Brown
X-11 Chrome Silver
XF-15 Flat Flesh
X-7 Red
XF-6 Copper
XF-1 Flat Black
XF-61 Dark Green

Specifications

ESCon either side for exceptional balance. 4-wheel double wishbone suspension features upper and lower H-arms and adjustable metal torsion bar springs. Fully-enclosed gearbox may be assembled with one of three different gear ratios. 1/12
ScaleLength: 400mm, Width: 168mm, Height: 139mm, Weight: 1,800g Wheelbase: 256mm, Tire Width/Diameter: (F/R) 29/77mm,
Tread(F/R): 138mm Type 540
MotorRear-Wheel Drive Duralumin Frame Chassis 3-Bevel Differential 2-piece Steering Tie-Rod 4-Wheel Double Wishbone Suspension with Metal Torsion Bar Springs Gear Ratio=9.3:1, 16:1, 21:1

Specifications

Brand Tamiya
