Power HD Micro Coreless Motor Plastic Gear Servo

Power HD Micro Coreless Motor Plastic Gear Servo

Now  $9.34

Description

Power HD-H1440A Servo. How To: Install a ServoIn this video, Hamish gives a step-by-step guide on installing a Servo and how to avoid stripping your servo gears. Power HD 1440A Servo Dimensions Total Height (A ) = 22.2mm. Body Width (B ) = 20.2mm. Below Mount (C ) = 16.3mm. Above Mount (D ) = 5.9mm. Total Length (E ) = 23.5mm. Total Width (F ) = 8.5mm. SpecificationsTorque(4.8V): 0.6 kg-cm (8.33 oz/in). Torque(6.0V): 0.8 kg-cm (11.10 oz/in). Speed: 0.12 sec (4.8V) ? 0.10 sec (6.0V). Operating Voltage?4.8 ~ 6.0 DC Volts. Weight: 4.4 g (0.15 oz). Bearing Type?No. Motor Type?Brushed. Gear Type?Plastic. Operating Temperature?-20?~60? . Working frequence?1520?s / 50hz. Size?20.2 x 8.5 x 20.2 mm ( 0.79 x 0.33 x 0.79 in). Included itemsDescription. QTY. Micro 0.8kg 6V Servo. 1. Servo Hardware Set. 1.

Specifications

Brand Power HD
