Dualsky XM2304TY-26 2300kv F3P Brushless Motor

Dualsky XM2304TY-26 2300kv F3P Brushless Motor

$74.99

Description

This is the Dualsky 2304 Typhoon series motor. It is great for micro speed models. Features - Weighs only 24.7 grams - 4mm hollow shaft - Sleek spoked design with a blue finish Specification - RPM/V (KV): 2300 - Weight (g): 24.7 - Diameter (mm): 28.2 - Length (mm): 22.6 - Diameter of Shaft (mm): 4, hollow - Pitch of holes (mm): 16/16,30/33 w/ motor mount - Input Connectors: GC2.0, 3 Pairs - Slots & Poles: 12N14P - lo@10V(A): 0.80 @7V - Resistance (Ri)(mOhm): 72.8 - No.of Cells(LiPo): 2S, 3S - Max. Efficiency Current(A): 11.5 - Max. Burst Current (15S)[A]: 23 - Max. Power (15S)[W]: 184 - Torque (mNM): 136 - Recommended ESC: XC-22-Lite, 15° (Middle) - Propeller: 2S: 8x4, 8x5, 9x4, 8x4 (3-Blade) 3S: 5x5, 6x3,6x4, 6x3 (3-Blade) - Applications: Micro Speed

Specifications

Brand Dualsky
