Dualsky ECO 4120C 500kv Brushless Motor suit Flex Cap 232EX and Laser 200

Dualsky ECO 4120C 500kv Brushless Motor suit Flex Cap 232EX and Laser 200

$129.99

Description

ECO V2 has made great improvements in many respects. It brought new electromagnetic design, more competitive performance and efficiency, long-time endurance and water-proof. This ECO 4120C 500kv motor is designed to be the electric equivalent of a .46 - .55 2-stroke engine. Features - Classic Dualsky five-spokes back cover with simple lines - Motor structure strength increased by 25% - Optimised stress distribution and strength increased without increasing the weight - High strength main shaft - High temperature resistant, high toughness epoxy glue - High precision double sides dynamic balancing - Waterproof splash (ball bearing not waterproof) - Rust-proof main shaft Specification - KV: 500 - Turns: 8 - Weight: 280g - Size (D x L): 49.5 x 45.2 - Slots & Poles: 12N14P - Ri (mOhm): 25 - Io @ 10V (A): 1.1 - No. of Cells (LiPo): 5S, 6S - Max. Efficiency Current (15S) [A]: 36 - Max. Burst Current (15S) [A]: 60 - Max. Power (15S) [W]: 1440 - Max. Torque: 1.38 - Shaft Diameter: 6 - Mounting Holes Pitch: 30/30 - Input Connectors: GC4.0 - Recommended ESC: XC-65-LITE or XC6018BA - Propeller: 5S: 16x8E, 15x8E or 6S: 14x7E, 15x8E - Class: .46-.55 2-stroke

Specifications

Brand Dualsky
