Dualsky ECO 3520C 1020kv Brushless Motor

Dualsky ECO 3520C 1020kv Brushless Motor

$103.99

Description

The 3520C ECO motor from Dualsky has 1020Kv of power. This motor comes with propeller and motor mounts, in addition to gold plugs and screws. Features - High strength, rust proof main shaft - Waterproof (ball bearing not waterproof) - High purity copper wire and temperature can reach 180 o C - Electromagnetic design - Optimised stress distribution and strength increased without increasing the weight Specification - KV: 1020 - Turns: 4 - Weight: 210g - Dimensions: 43.2 x 42.4mm - Slots & Poles: 12N14P - Ri (mOhm): 10.8 - Io@10V: 2.6 - No. of cells: 3..4 - Max. Efficiency Current [A]: 48 - Max. Burst Current (15S) [A]: 80 - Max. Power (15S)[A]: 960 - Max. Torque [N*M]: 0.9 - Shaft diameter: 6mm - Mounting holes pitch: 25/25 - Input Connectors: GC4.0 - Recommended ESC: XC8018BA - Propeller: 3S: 14x7E, 13x6.5E / 4S: 11x535E, 10x5E: - Class: .50 4-Stroke .32-.0 (40E) 2-Stroke

Specifications

Brand Dualsky
