Dualsky ECO 2304C 2300kv Brushless Motor

Dualsky ECO 2304C 2300kv Brushless Motor

$39.99

Description

The 2304C ECO motor from Dualsky has 2300kv of power and is a great choice for indoor RC planes. This motor comes with propeller and motor mounts, in addition to gold plugs and screws. Features - Classic Dualsky five-spoke back cover - Traditional Dualsky colour matching, anodized and matte finish - Multi-surface rotating laser markings - Motor structure strength increased by 25% over previous generations - Optimised stress distribution - Tough main shaft - High precision - Splashproof (please note, ball bearing is not waterproof) Specification - RPM/V (KV): 2300 - Turns: 14.5 - Weight (g): 23 - Dimensions: 28.5x16.7 - Diameter of Shaft (mm): 3.175 - No of Cells: 2S, 3S LiPo - Slots, Poles: 12N14P - Idle Current (Io) @ 10V: 0.6 - Max Efficiency Current (A): 9 - Max Torque [N*M]: 0.075 - Max Burst Current (15S) [A]: 15 - Max Power (W) [15S]: 120 - Mounting Holes Pitch: 32 - Recommended ESC: XC-12 Lite or XC1210BA - Propeller: 2S: 8.3E, PT 9x2.8i/ 3S: 5.1x4.5E - Class: 100-200g airplane - Input Connectors: GC2.0 - Ri(mOhm): 103

Specifications

Brand Dualsky
